Fendt Farmer 102 S

Fendt Farmer 102 S är en traktor med motorbeteckningen MWM MOTORENWERKE MANNHEIM AG D 226-3 och slagvolym 3 116 cm³. Uppmätt motoreffekt i provet: 34,7 kW.

Underlag för modellbeskrivningen

Faktarader: Motortillverkare · Motormodell · Slagvolym · Maximal uppmätt motoreffekt i separat tvåtimmarsprov

Källor: Fendt Farmer 102 S Turbomatik — DLG/OECD Report No. 518 Källpost

Motortyp enligt rapporten
4-takts dieselmotor med direktinsprutning; vattenkyld.
Maximalt uppmätt motormoment
176 Nm
Koppling enligt provexemplarets transmissionsbeskrivning
VOITH GETRIEBE KG vätskekoppling 332 TD; för körning och kraftuttagsdrift.
Hydraulisk lyftreglering
Dragkraftsreglering och lägesreglering kan blandas steglöst; flytläge.
Fendt Farmer 102 S Turbomatik fotograferad från sidan; modell- och Turbomatik-emblemen syns på motorhuven.
Fendt Farmer 102 S Turbomatik enligt synligt emblem och Commons filbeskrivning. Referensfoto fotograferat 2012; det visar inte DLG-provets enskilda traktor.
Foto: Wleiter, “Fendt Farmer 102S Turbomatik (1973, 45 PS),” Wikimedia Commons, CC BY-SA 3.0. Proportionellt förminskad till 1280 × 960 px; EXIF borttaget. · Licens · Bildkälla

Översikt

Kraft, fart och format.

Fendt Farmer 102 S

Alla tekniska data

Motoreffekt

Maximal uppmätt motoreffekt i separat tvåtimmarsprov34,7 kWMätvärdet gäller den angivna provuppställningen och villkoren; det överförs inte automatiskt till alla traktorer.Fakta

Hastighet

Nominell hastighet i oberoende snabbväxelVisad hastighet 24,16 km/h på skalan 0 till 25 km/h.012,525

24,16 km/h

Detta utförande hålls åtskilt från andra modell- och provutföranden.

Fakta

Motor

Slagvolym3116 cm³Fakta

Mått

Axelavstånd2 078 mmFakta
Längd med trepunkt, utan ballast3 670 mmFakta
Fler mått
Längd med trepunkt och ballast3 780 mmFakta
Bredd vid minsta och största spårvidd1736 mm vid minsta spårvidd och 2185 mm vid största spårvidd; båda måtten utan ballast.Fakta
Höjd till rattens och ramens ovansida1580 till rattens överkant; 2320 mm till skyddsramens överkant.Fakta

Hydraulik

Flödesuppgifter per källrad och utförande

Pumpflöde vid minimitryck33,6 L/min
Fakta
Fler flödesuppgifter
Pumpflöde vid 162 bars provtryck25,9 L/min
Fakta

Tekniska data

Motor och effekt

Farmer 102 S · Motor och effekt
UppgiftVärde och utförandeKälla
MotortillverkareMWM MOTORENWERKE MANNHEIM AG som angivet
Källa

Originalvärde: MWM MOTORENWERKE MANNHEIM AG as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Engine — Make.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Engine — Make",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "MWM MOTORENWERKE MANNHEIM AG",
  "printedUnit": "no separate unit"
}
MotormodellD 226-3 som angivet
Källa

Originalvärde: D 226-3 as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Engine — Model.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Engine — Model",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "D 226-3",
  "printedUnit": "no separate unit"
}
Motortyp enligt rapporten4-takts dieselmotor med direktinsprutning; vattenkyld.
Källa

Originalvärde: 4-stroke diesel engine with direct injection; watercooled as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Engine — Type.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Engine — Type",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "4-stroke DIESEL engine with direct injection; watercooled",
  "printedUnit": "no separate unit"
}
Cylinderutförande3 in-line som angivet
Källa

Originalvärde: 3 in-line as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Engine — Cylinders.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Engine — Cylinders",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "3 in-line",
  "printedUnit": "no separate unit"
}
Cylinderdiameter105 mm
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Engine — Cylinders.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Engine — Cylinders",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "105",
  "printedUnit": "mm"
}
Slaglängd120 mm
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Engine — Cylinders.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Engine — Cylinders",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "120",
  "printedUnit": "mm"
}
Slagvolym3116 cm³
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Engine — Cylinders / displacement.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Engine — Cylinders / displacement",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "3116",
  "printedUnit": "cm³"
}
Kompressionsförhållande17:1 ratio
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Engine — Cylinders / compression ratio.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Engine — Cylinders / compression ratio",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "17:1",
  "printedUnit": "ratio"
}
VentilplaceringOverhead som angivet
Källa

Originalvärde: Overhead as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Engine — Valves.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Engine — Valves",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "Overhead",
  "printedUnit": "no separate unit"
}
Märkvarvtal enligt DLG-specifikationen2175 varv/min
Källa

Originalvärde: 2175 rev/min

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Governor — rated engine speed.

Villkor: This is the report's engine-speed specification, not a rated-power declaration.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Governor — rated engine speed",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "2175",
  "printedUnit": "rev/min"
}
Reglerat motorvarvtalsområde650–2280 varv/min
Källa

Originalvärde: 650–2280 rev/min

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Governor — governed range of engine speed.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Governor — governed range of engine speed",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "650 to 2280",
  "printedUnit": "rev/min"
}
StartmotorBOSCH startmotor, 1.84 kW.
Källa

Originalvärde: BOSCH starter motor with 1.84 kW

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.5 (printed p.5), Starting system.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 5,
  "printedPage": 5,
  "row": "Starting system",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "BOSCH starter motor with 1.84 kW",
  "printedUnit": "kW"
}
Maximal uppmätt motoreffekt i separat tvåtimmarsprov34.7 kW

Mätvärdet gäller den angivna provuppställningen och villkoren; det överförs inte automatiskt till alla traktorer. · Standard ej angiven

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: Optional DLG engine performance test; no separate named engine-power standard stated for this row.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.31 (printed p.29), Optional tests — Engine performance — At maximum power 2-hour test.

Villkor: This is an optional DLG measured engine test result, not a stated manufacturer rated-power standard. Keep separate from the PTO-shaft results on printed p.17.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 31,
  "printedPage": 29,
  "row": "Optional tests — Engine performance — At maximum power 2-hour test",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "34,7 kW at 2175 rev/min",
  "printedUnit": "kW at engine rev/min"
}
Maximalt uppmätt motormoment176 Nm

Detta utförande hålls åtskilt från andra modell- och provutföranden.

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: Optional DLG engine performance test; torque standard not separately stated.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.31 (printed p.29), Optional tests — Engine performance — Maximum torque.

Villkor: Report does not state a separate torque standard for this cell; do not label it DIN/ISO without other support.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 31,
  "printedPage": 29,
  "row": "Optional tests — Engine performance — Maximum torque",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "Maximum torque 176 Nm at 1400 rev/min of the engine",
  "printedUnit": "Nm at engine rev/min"
}
Bästa specifika bränsleförbrukning i motorprovet212 g/kWh

Mätvärdet gäller den angivna provuppställningen och villkoren; det överförs inte automatiskt till alla traktorer.

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: Optional DLG engine performance test; no separate named fuel-consumption standard stated for this row.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.31 (printed p.29), Optional tests — Engine performance — Optimum fuel consumption.

Villkor: Test result under the stated operating point; not a universal operating consumption value.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 31,
  "printedPage": 29,
  "row": "Optional tests — Engine performance — Optimum fuel consumption",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "212 g/kWh at 20.5 kW and 1300 rev/min",
  "printedUnit": "g/kWh"
}

Transmission

Farmer 102 S · Transmission
UppgiftVärde och utförandeKälla
Koppling enligt provexemplarets transmissionsbeskrivningVOITH GETRIEBE KG vätskekoppling 332 TD; för körning och kraftuttagsdrift.

Rapporten anger detta som koppling (1) i transmissionsbeskrivningen.

Källa

Originalvärde: VOITH GETRIEBE KG fluid clutch 332 TD; for travel and p.t.o. drive as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.6 (printed p.6), Transmission — Clutch (1).

Villkor: The report lists this as clutch (1) on physical p.6. It does not label clutch (2) optional; do not infer an optional/fitted status for clutch (2).

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 6,
  "printedPage": 6,
  "row": "Transmission — Clutch (1)",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "VOITH GETRIEBE KG; fluid clutch 332 TD; for travel and p.t.o. drive",
  "printedUnit": "no separate unit"
}
Koppling 2 i rapportens transmissionsbeskrivningFICHTEL UND SACHS AG G 250 K torr skivkoppling; endast för körning.

Rapporten anger koppling (2), men fastställer inte om den var monterad på provtraktorn eller ett tillval.

Källa

Originalvärde: FICHTEL UND SACHS AG G 250 K dry disc clutch; for travel drive only as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.6 (printed p.6), Transmission — Clutch (2).

Villkor: The report lists this as clutch (2) on physical p.6 but does not state whether it was fitted to or optional for the tested tractor. Infer neither status.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 6,
  "printedPage": 6,
  "row": "Transmission — Clutch (2)",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "FICHTEL UND SACHS AG; dry disc type clutch G 250 K; flexible coated; for travel drive only; pedal operated",
  "printedUnit": "no separate unit"
}
Växlar framåt och bakåt13 framåt; 4 bakåt.
Källa

Originalvärde: 13 forward; 4 reverse gears

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.6 (printed p.6), Transmission — Gear box.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 6,
  "printedPage": 6,
  "row": "Transmission — Gear box",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "totally 13 forward and 4 reverse speeds",
  "printedUnit": "speeds"
}
Nominell hastighet i oberoende snabbväxel24.16 km/h

Detta utförande hålls åtskilt från andra modell- och provutföranden.

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.8 (printed p.8), Total ratios and speeds — Independent high speed gear.

Villkor: A calculated nominal travelling speed, not a separately measured road-speed result.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 8,
  "printedPage": 8,
  "row": "Total ratios and speeds — Independent high speed gear",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "Independent high speed gear: 24.16 km/h",
  "printedUnit": "km/h"
}

Hydraulik och lyft

Farmer 102 S · Hydraulik och lyft
UppgiftVärde och utförandeKälla
Hydraulisk lyftregleringDragkraftsreglering och lägesreglering kan blandas steglöst; flytläge.
Källa

Originalvärde: Power control and position control, both steplessly mixable; floating position as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.10 (printed p.10), Power lift — Hydraulic system.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 10,
  "printedPage": 10,
  "row": "Power lift — Hydraulic system",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "power control, position control, both stepless mixable, floating position",
  "printedUnit": "no separate unit"
}
Hydraulpumpens slagvolym14 cm³/rev

Detta utförande hålls åtskilt från andra modell- och provutföranden.

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.10 (printed p.10), Power lift — Hydraulic system.

Villkor: Report adds a separate 16 cm³/rev Bosch pump if hydrostatic steering is fitted; 14 cm³/rev is the stated pump in the main specification text.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 10,
  "printedPage": 10,
  "row": "Power lift — Hydraulic system",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "BOSCH gear type pump with 14 cm³/rev delivery",
  "printedUnit": "cm³/rev"
}
Maximalt oljetryck i lyftspecifikationen175 bar

Detta utförande hålls åtskilt från andra modell- och provutföranden.

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.10 (printed p.10), Power lift — Hydraulic system.

Villkor: Specification cell; the separate p.25 hydraulic pump test reports remote-circuit relief opening/sustained pressures under test conditions.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 10,
  "printedPage": 10,
  "row": "Power lift — Hydraulic system",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "maximum oil pressure 175 bar",
  "printedUnit": "bar"
}
Tryck i separat hydraulikprov177 opening; 172 sustained bar

Mätvärdet gäller den angivna provuppställningen och villkoren; det överförs inte automatiskt till alla traktorer.

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.27 (printed p.25), Hydraulic pump — opening pressure of relief valve in remote circuit; sustained pressure by open relief valve.

Villkor: Test readings in the remote circuit; keep separate from the 175 bar specification cell on physical p.10.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 27,
  "printedPage": 25,
  "row": "Hydraulic pump — opening pressure of relief valve in remote circuit; sustained pressure by open relief valve",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "177 bar; 172 bar",
  "printedUnit": "bar"
}
Pumpflöde vid minimitryck33.6 l/min
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.27 (printed p.25), Hydraulic pump — delivery rate at minimum pressure and maximum engine speed.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 27,
  "printedPage": 25,
  "row": "Hydraulic pump — delivery rate at minimum pressure and maximum engine speed",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "33.6 l/min",
  "printedUnit": "l/min"
}
Pumpflöde vid 162 bars provtryck25.9 l/min
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.27 (printed p.25), Hydraulic pump — pump delivery rate.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 27,
  "printedPage": 25,
  "row": "Hydraulic pump — pump delivery rate",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "25.9 l/min",
  "printedUnit": "l/min"
}
Hydraulisk effekt vid flödesprovet7.0 kW

Standard ej angiven

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.27 (printed p.25), Hydraulic pump — hydraulic power.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 27,
  "printedPage": 25,
  "row": "Hydraulic pump — hydraulic power",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "7.0 kW",
  "printedUnit": "kW"
}
Hydrauloljetank och uttagbar oljemängdTank på 15.5 l; upp till 7.5 l kan tas ut till externa cylindrar under körning/arbete och 10 l när traktorn står stilla.
Källa

Originalvärde: 15.5 l tank; up to 7.5 l available for remote rams while driving/working and 10 l when stationary as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.10 (printed p.10), Power lift — Hydraulic system.

Villkor: The available remote-cylinder volume is expressly conditional on driving/working versus stationary operation.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 10,
  "printedPage": 10,
  "row": "Power lift — Hydraulic system",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "oil tank 15.5 l; maximal 7.5 l may be taken off for remote rams when tractor is working driving and 10 l when stationary",
  "printedUnit": "l"
}
Trepunktens kategoriCategory II; Category I optionally available som angivet
Källa

Originalvärde: Category II; Category I optionally available as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.10 (printed p.10), Implement linkage.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 10,
  "printedPage": 10,
  "row": "Implement linkage",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "Three point linkage, category II (DIN 9674); category I is optionally available",
  "printedUnit": "no separate unit"
}

Kraftuttag

Farmer 102 S · Kraftuttag
UppgiftVärde och utförandeKälla
Bakre kraftuttag vid 540-varvsläge586 varv/min vid motorvarvtal 2175 varv/min; standard kraftuttag 540 varv/min vid motorvarvtal 2013.

Källan anger att cirka 3,1 % slirning i vätskekopplingen ingår i samtliga redovisade kraftuttagsvarvtal.

Källa

Originalvärde: 586 at 2175 engine rev/min; standard 540 PTO rev/min at 2013 engine rev/min rev/min

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.7 (printed p.7), Main power take-off — 540 rev/min p.t.o..

Villkor: Report states approx. 3.1% fluid-clutch slip is included in all PTO speeds quoted.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 7,
  "printedPage": 7,
  "row": "Main power take-off — 540 rev/min p.t.o.",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "540 rev/min PTO; 586 rev/min at rated engine speed; standard PTO-speed 540 rev/min at 2013 rev/min engine speed",
  "printedUnit": "rev/min"
}
Bakre kraftuttag vid 1000-varvsläge1045 varv/min vid motorvarvtal 2175 varv/min; standard kraftuttag 1000 varv/min vid motorvarvtal 2083.

Källan anger att cirka 3,1 % slirning i vätskekopplingen ingår i samtliga redovisade kraftuttagsvarvtal.

Källa

Originalvärde: 1045 at 2175 engine rev/min; standard 1000 PTO rev/min at 2083 engine rev/min rev/min

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.7 (printed p.7), Main power take-off — 1000 rev/min p.t.o..

Villkor: Report states approx. 3.1% fluid-clutch slip is included in all PTO speeds quoted.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 7,
  "printedPage": 7,
  "row": "Main power take-off — 1000 rev/min p.t.o.",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "1000 rev/min PTO; 1045 rev/min at rated engine speed; PTO-speed 1000 rev/min at 2083 rev/min engine speed",
  "printedUnit": "rev/min"
}
Främre kraftuttagTillval; inte monterat på den provade traktorn.

Tillval; inte monterat på den provade traktorn.

Källa

Originalvärde: Optional; not fitted on tractor tested as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.9 (printed p.9), Front p.t.o..

Villkor: An option described by the report, not test-exemplar equipment.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 9,
  "printedPage": 9,
  "row": "Front p.t.o.",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "Optional, not fitted on tractor tested",
  "printedUnit": "no separate unit"
}
Markhastighetsberoende kraftuttagMarkhastighetsberoende kraftuttag: tillval, inte monterat på den provade traktorn.

Tillval; inte monterat på den provade traktorn.

Källa

Originalvärde: Optional; not fitted on tractor tested as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.9 (printed p.9), Ground speed p.t.o..

Villkor: An option described by the report, not test-exemplar equipment.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 9,
  "printedPage": 9,
  "row": "Ground speed p.t.o.",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "Optional, not fitted on tractor tested",
  "printedUnit": "no separate unit"
}
Maximal uppmätt effekt vid kraftuttagsaxeln31.1 kW

Mätvärdet gäller den angivna provuppställningen och villkoren; det överförs inte automatiskt till alla traktorer. · OECD

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: DLG/OECD compulsory PTO performance test; measured PTO shaft output, not engine output.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.19 (printed p.17), Compulsory tests — Main power take-off performance — At maximum power 2-hour test.

Villkor: Measured at the PTO shaft; do not present as engine rated power. Physical p.18 errata changes three part-load values on this table; this maximum-power row is not one of them.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 19,
  "printedPage": 17,
  "row": "Compulsory tests — Main power take-off performance — At maximum power 2-hour test",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "31,1 kW; engine 2175 rev/min; p.t.o. 586 rev/min",
  "printedUnit": "kW; engine rev/min; PTO rev/min"
}
Uppmätt kraftuttagseffekt vid standardiserat 540-varvsläge29.8 kW

Mätvärdet gäller den angivna provuppställningen och villkoren; det överförs inte automatiskt till alla traktorer. · OECD

Källa

Originalrubrik: Uppmätt PTO-effekt vid standardiserat 540-varvsläge

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: DLG/OECD compulsory PTO performance test; measured PTO shaft output, not engine output.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.19 (printed p.17), Compulsory tests — Main power take-off performance — At standard p.t.o. speed (540 rev/min).

Villkor: Measured at the PTO shaft; distinct from engine output. This standard-speed row is not altered by physical p.18 errata.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 19,
  "printedPage": 17,
  "row": "Compulsory tests — Main power take-off performance — At standard p.t.o. speed (540 rev/min)",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "29,8 kW; engine 2012 rev/min; PTO 540 rev/min",
  "printedUnit": "kW; engine rev/min; PTO rev/min"
}

Underrede och band

Farmer 102 S · Underrede och band
UppgiftVärde och utförandeKälla
Framdäck på DLG-provexemplaret7.50-16 AS; 6 ply däckdimension / ply rating

Uppgiften gäller rapportens provtraktor och fastställer inte däckutrustningen på alla Farmer 102 S.

Källa

Originalrubrik: Framdäck enligt provspecifikationen

Originalvärde: 7.50-16 AS; 6 ply tyre size / ply rating

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.12 (printed p.12), Wheels — Steering wheels.

Villkor: Tyre size/equipment stated for the tractor described in the report; optional wheel/track configurations are listed separately.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 12,
  "printedPage": 12,
  "row": "Wheels — Steering wheels",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "front 7.50-16 AS; 6 ply",
  "printedUnit": "tyre size; ply"
}
Bakdäck på DLG-provexemplaret14.9-30 AS; 6 ply däckdimension / ply rating

Uppgiften gäller rapportens provtraktor och fastställer inte däckutrustningen på alla Farmer 102 S.

Källa

Originalrubrik: Bakdäck enligt provspecifikationen

Originalvärde: 14.9-30 AS; 6 ply tyre size / ply rating

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.12 (printed p.12), Wheels — Driving wheels.

Villkor: Tyre size/equipment stated for the tractor described in the report; optional wheel/track configurations are listed separately.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 12,
  "printedPage": 12,
  "row": "Wheels — Driving wheels",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "rear 14.9-30 AS; 6 ply",
  "printedUnit": "tyre size; ply"
}
Högsta tillåtna last per framdäck enligt rapporten856 kg per däck

Per framdäck vid 2.25 bar däcktryck och 25 km/h enligt DLG-rapporten.

Källa

Originalvärde: 856 kg per tyre

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.12 (printed p.12), Wheels — Steering wheels.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 12,
  "printedPage": 12,
  "row": "Wheels — Steering wheels",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "max. permissible load on each tyre 856 kg at 2.25 bar inflation pressure and 25 km/h",
  "printedUnit": "kg each; bar; km/h"
}
Högsta tillåtna last per bakdäck enligt rapporten1780 kg per däck

Per bakdäck vid 1.4 bar däcktryck och 25 km/h enligt DLG-rapporten.

Källa

Originalvärde: 1780 kg per tyre

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.12 (printed p.12), Wheels — Driving wheels.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 12,
  "printedPage": 12,
  "row": "Wheels — Driving wheels",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "max. permissible load on each tyre 1780 kg at 1.4 bar inflation pressure and 25 km/h",
  "printedUnit": "kg each; bar; km/h"
}
Framfälg enligt DLG-provspecifikationen5,50 F x 16 B

Beteckningen kommer från rapportens provspecifikation och fastställer inte en generell fälgdimension för alla Farmer 102 S.

Källa

Originalrubrik: Framfälg enligt DLG-rapportens provspecifikation

Utförande: Front-rim designation in the Wheels — Steering wheels specification for Fendt Farmer 102 S Turbomatik in DLG/OECD Report No. 518; not a universal fitment claim.

Standard och villkor: Wheel specification as printed; no separate standard is stated for this cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.12 (printed p.12), Wheels — Steering wheels: exact cell text “rims 5,50 F x 16 B.”

Villkor: Fälgbeteckning i rapportens provspecifikation; rapporten fastställer inte att dimensionen gäller alla Farmer 102 S.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-15

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 12,
  "printedPage": 12,
  "row": "Wheels — Steering wheels; rims",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "rims 5,50 F x 16 B",
  "printedUnit": null
}

Mått och vikt

Farmer 102 S · Mått och vikt
UppgiftVärde och utförandeKälla
Axelavstånd2078 mm
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.12 (printed p.12), Wheel base.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 12,
  "printedPage": 12,
  "row": "Wheel base",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "2078",
  "printedUnit": "mm"
}
Provexemplar med ram utan ballast, inklusive förare2525 kg

Mätvärdet gäller den angivna provuppställningen och villkoren; det överförs inte automatiskt till alla traktorer.

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.13 (printed p.13), Weights — Ready for use as tested with frame / Without ballast / Total / with driver.

Villkor: A weighed test configuration, not an unqualified catalogue mass.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 13,
  "printedPage": 13,
  "row": "Weights — Ready for use as tested with frame / Without ballast / Total / with driver",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "2525 kg",
  "printedUnit": "kg"
}
Provexemplar med ram och ballast, inklusive förare3975 kg

Mätvärdet gäller den angivna provuppställningen och villkoren; det överförs inte automatiskt till alla traktorer.

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.13 (printed p.13), Weights — Ready for use as tested with frame / With ballast / Total / with driver.

Villkor: A weighed test configuration. The report separately lists front plate/weights, rear wheel weights and water in tyres.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 13,
  "printedPage": 13,
  "row": "Weights — Ready for use as tested with frame / With ballast / Total / with driver",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "3975 kg",
  "printedUnit": "kg"
}
Längd med trepunkt, utan ballast3670 mm
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.14 (printed p.14), Dimensions — Total length.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 14,
  "printedPage": 14,
  "row": "Dimensions — Total length",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "3670 mm with 3 point linkage without ballast",
  "printedUnit": "mm"
}
Längd med trepunkt och ballast3780 mm
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.14 (printed p.14), Dimensions — Total length.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 14,
  "printedPage": 14,
  "row": "Dimensions — Total length",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "3780 mm with 3 point linkage with ballast",
  "printedUnit": "mm"
}
Bredd vid minsta och största spårvidd1736 mm vid minsta spårvidd och 2185 mm vid största spårvidd; båda måtten utan ballast.
Källa

Originalvärde: 1736 at smallest track width; 2185 at largest track width mm

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.14 (printed p.14), Dimensions — Total width.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 14,
  "printedPage": 14,
  "row": "Dimensions — Total width",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "1736 mm at smallest track width; 2185 mm at largest track width without ballast",
  "printedUnit": "mm"
}
Höjd till rattens och ramens ovansida1580 till rattens överkant; 2320 mm till skyddsramens överkant.
Källa

Originalvärde: 1580 to top of steering wheel; 2320 to top of frame mm

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.14 (printed p.14), Dimensions — Total height.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 14,
  "printedPage": 14,
  "row": "Dimensions — Total height",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "1580 mm to top of steering wheel; 2320 mm to top of frame",
  "printedUnit": "mm"
}
Markfrigång under framaxeln425 mm
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.14 (printed p.14), Dimensions — Ground clearance.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 14,
  "printedPage": 14,
  "row": "Dimensions — Ground clearance",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "425 mm in tractor's median plane below the front axle",
  "printedUnit": "mm"
}
Spårvidd fram enligt DLG-rapporten1250, 1360 och 1500 mm

Rapporten anger tre alternativa inställningar fram, ändrade med teleskopiska halva framaxlar.

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518; these are the report's listed front-track settings, not a model-year or production-range claim.

Standard och villkor: Wheel specification under the report's Wheels — Steering wheels section; no separate standard is stated for this cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.12 (printed p.12), Wheels — Steering wheels: exact cell text “track width 1250, 1360 and 1500 mm; changing by telescopic half axles.”

Villkor: Rapporten listar tre spårviddsinställningar fram och anger teleskopiska halva framaxlar för ändring; värdena är inte tre samtidiga mått.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-15

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 12,
  "printedPage": 12,
  "row": "Wheels — Steering wheels; track width",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "track width 1250, 1360 and 1500 mm; changing by telescopic half axles",
  "printedUnit": "mm"
}
Spårvidd bak enligt DLG-rapporten1360 och 1500 mm

Rapporten anger två alternativa inställningar bak, ändrade genom att vända hjulen.

Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518; these are the report's listed rear-track settings, not a model-year or production-range claim.

Standard och villkor: Wheel specification under the report's Wheels — Driving wheels section; no separate standard is stated for this cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.12 (printed p.12), Wheels — Driving wheels: exact cell text “track width 1360 and 1500 mm; changeable by reversing wheels.”

Villkor: Rapporten listar två spårviddsinställningar bak och anger att de ändras genom att vända hjulen; värdena är inte två samtidiga mått.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-15

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 12,
  "printedPage": 12,
  "row": "Wheels — Driving wheels; track width",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "track width 1360 and 1500 mm; changeable by reversing wheels",
  "printedUnit": "mm"
}
Valbart bakre spårviddsområde1362–1850 mm

Separat tillval med vändbara och förskjutna fälgar av klacktyp; rapporten anger att det inte var monterat på provtraktorn.

Källa

Originalrubrik: Valbart bakre spårviddsområde med justeringshjul

Utförande: Optional rear track-adjustment equipment described in DLG/OECD Report No. 518; the report explicitly says it was not fitted on the tractor tested.

Standard och villkor: Optional wheel specification under the report's Wheels — Driving wheels section; no separate standard is stated for this cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.12 (printed p.12), Wheels — Driving wheels, parenthetical optional note: track-adjustment wheels are optionally available from 1362 to 1850 mm using turning and offset lug-type rims; not fitted on the tractor tested.

Villkor: Separat tillval enligt rapporten, med vändbara och förskjutna fälgar av klacktyp; DLG anger uttryckligen att tillvalet inte var monterat på provtraktorn.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-15

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 12,
  "printedPage": 12,
  "row": "Wheels — Driving wheels; optional track-adjustment note",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "track adjustment wheels are optionally available for track width from 1362 to 1850 mm by turning and offset lug type rims, not fitted on tractor tested",
  "printedUnit": "mm"
}

Övriga uppgifter

Farmer 102 S · Övriga uppgifter
UppgiftVärde och utförandeKälla
Modellbeteckning i DLG-rapportenFARMER 102 S TURBOMATIK som angivet
Källa

Originalvärde: FARMER 102 S TURBOMATIK as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Tractor — Model.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Tractor — Model",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "FARMER 102 S TURBOMATIK",
  "printedUnit": "no separate unit"
}
Traktortyp och drivning enligt rapportenWheeled tractor, unit construction, rear wheel driven som angivet
Källa

Originalvärde: Wheeled tractor, unit construction, rear wheel driven as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Tractor — Type.

Villkor: This is the report's tested tractor type; it does not define all market variants.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Tractor — Type",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "Wheeled tractor, unit construction, rear wheel driven",
  "printedUnit": "no separate unit"
}
Serienummer för DLG-provexemplaret138/01/0007 som angivet
Källa

Originalvärde: 138/01/0007 as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Tractor — Serial No..

Villkor: Identifies the individual test specimen only; it is not a series or PIN range.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Tractor — Serial No.",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "138/01/0007",
  "printedUnit": "no separate unit"
}
Bränsletankens kapacitet73 l
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.4 (printed p.4), Fuel system — fuel tank capacity.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 4,
  "printedPage": 4,
  "row": "Fuel system — fuel tank capacity",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "73",
  "printedUnit": "l"
}
KylsystemVattenkylning med impellerpump; trycksatt system inställt för 0.3 bar övertryck och bypass-termostat.
Källa

Originalvärde: Water cooling with impeller pump; pressurized system adjusted to 0.3 bar overpressure with by-pass thermostat as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.5 (printed p.5), Cooling system.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 5,
  "printedPage": 5,
  "row": "Cooling system",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "Water cooling with impeller pump; pressurized system adjusted to 0,3 bar overpressure with by-pass thermostat",
  "printedUnit": "no separate unit"
}
Kylfläkt enligt provspecifikationen7 blades; 410 mm diameter
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.5 (printed p.5), Cooling system — fan.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 5,
  "printedPage": 5,
  "row": "Cooling system — fan",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "7 blades; 410 mm diameter",
  "printedUnit": "blades; mm diameter"
}
Kylsystemets vattenmängd10 l
Källa

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.5 (printed p.5), Cooling system — water capacity.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 5,
  "printedPage": 5,
  "row": "Cooling system — water capacity",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "10",
  "printedUnit": "l"
}
Elsystem och batteri12 Volt; minusjordning; BOSCH trefasgenerator; 1 blybatteri märkt 88 Ah vid 20 timmars urladdningstid.
Källa

Originalvärde: 12 Volt, negative earth; BOSCH three phase alternator; 1 lead acid battery rated 88 Ah at 20 hours as stated

Utförande: Fendt Farmer 102 S Turbomatik as named in DLG/OECD Report No. 518. Values are bounded to the report's tested specimen/configuration and stated conditions; no generation, model-year, production-span or sales-market inference.

Standard och villkor: No separate performance standard is stated for this specification cell.

Marknad: German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.

Källperiod: Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Underlag: DLG/OECD Report No. 518, physical PDF p.5 (printed p.5), Electrical equipment.

Publicerad: O.E.C.D. Report No. 518; printed June 1976; approved 28 April 1976; test dates September–October 1975.

Läst: 2026-10-08

Källcellens text och dokumentlocator
{
  "physicalPdfPage": 5,
  "printedPage": 5,
  "row": "Electrical equipment",
  "modelColumn": "Fendt Farmer 102 S Turbomatik; test specimen serial 138/01/0007 where stated.",
  "printedCellValue": "12 Volt, negative earth; BOSCH three phase alternator; 1 lead acid battery 88 Ah at 20 hours rating",
  "printedUnit": "V; Ah at 20-hour rating"
}

Motor och maskindata

Motor och effekt

Fendt Farmer 102 S · Motor och effekt
UppgiftVärde och utförandeKälla
MotortypD-226-3

Utförande Farmer 102 S Turbomatic, OECD 518 · engine

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: engine

Kraftuttag

Fendt Farmer 102 S · Kraftuttag
UppgiftVärde och utförandeKälla
Kraftuttagseffekt31,1 kW

Utförande Farmer 102 S Turbomatic, OECD 518 · PTO · 2-hour PTO at rated engine speed, PTO 586

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 31,1 kW kW

Sidangivelse: Tryckt sida 17

Utförande: Farmer 102 S Turbomatic, OECD 518

Norm: PTO

Mätning: 2-hour PTO at rated engine speed, PTO 586

Kraftuttagseffekt29,8 kW

Utförande Farmer 102 S Turbomatic, OECD 518 · PTO · maximum power at standard PTO speed 540

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 29,8 kW kW

Sidangivelse: Tryckt sida 17

Utförande: Farmer 102 S Turbomatic, OECD 518

Norm: PTO

Mätning: maximum power at standard PTO speed 540

Transmission och drivning

Fendt Farmer 102 S · Transmission och drivning
UppgiftVärde och utförandeKälla
TransmissionEgen växellåda med treväxel, fält- och väggrupp, finsteg och högväxel samt Voith-vätskekoppling

Utförande Farmer 102 S Turbomatic, OECD 518 · gearbox

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: gearbox

Framåtväxlar13 växlar

Utförande Farmer 102 S Turbomatic, OECD 518 · tested tractor, creep group not fitted

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 13 forward speeds gears

Utförande: Farmer 102 S Turbomatic, OECD 518

Villkor: tested tractor, creep group not fitted

Backväxlar4 växlar

Utförande Farmer 102 S Turbomatic, OECD 518 · gearbox

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 4 reverse speeds gears

Utförande: Farmer 102 S Turbomatic, OECD 518

System: gearbox

Drivning2WD

Utförande Farmer 102 S Turbomatic, OECD 518 · axles

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: axles

Mått, vikt och däck

Fendt Farmer 102 S · Mått, vikt och däck
UppgiftVärde och utförandeKälla
Vikt2 450 kg

Utförande Farmer 102 S Turbomatic, OECD 518 · with frame, unballasted, without driver

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 2450 kg kg

Utförande: Farmer 102 S Turbomatic, OECD 518

Mätning: with frame, unballasted, without driver

Vikt2 525 kg

Utförande Farmer 102 S Turbomatic, OECD 518 · with frame, unballasted, with driver

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 2525 kg kg

Utförande: Farmer 102 S Turbomatic, OECD 518

Mätning: with frame, unballasted, with driver

Vikt3 900 kg

Utförande Farmer 102 S Turbomatic, OECD 518 · with frame, ballasted, without driver

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 3900 kg kg

Utförande: Farmer 102 S Turbomatic, OECD 518

Mätning: with frame, ballasted, without driver

Vikt3 975 kg

Utförande Farmer 102 S Turbomatic, OECD 518 · with frame, ballasted, with driver

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 3975 kg kg

Utförande: Farmer 102 S Turbomatic, OECD 518

Mätning: with frame, ballasted, with driver

Hjulbas2 078 mm

Utförande Farmer 102 S Turbomatic, OECD 518 · wheelbase

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 2078 mm mm

Utförande: Farmer 102 S Turbomatic, OECD 518

Mätning: wheelbase

Längd3 670 mm

Utförande Farmer 102 S Turbomatic, OECD 518 · overall length with three-point linkage, without ballast

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 3670 mm mm

Utförande: Farmer 102 S Turbomatic, OECD 518

Mätning: overall length with three-point linkage, without ballast

Längd3 780 mm

Utförande Farmer 102 S Turbomatic, OECD 518 · overall length with three-point linkage, with ballast

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 3780 mm mm

Utförande: Farmer 102 S Turbomatic, OECD 518

Mätning: overall length with three-point linkage, with ballast

Bredd1 736 mm

Utförande Farmer 102 S Turbomatic, OECD 518 · overall width at smallest track, without ballast

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 1736 mm mm

Utförande: Farmer 102 S Turbomatic, OECD 518

Mätning: overall width at smallest track, without ballast

Bredd2 185 mm

Utförande Farmer 102 S Turbomatic, OECD 518 · overall width at largest track, without ballast

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 2185 mm mm

Utförande: Farmer 102 S Turbomatic, OECD 518

Mätning: overall width at largest track, without ballast

Höjd1 580 mm

Utförande Farmer 102 S Turbomatic, OECD 518 · to top of steering wheel

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 1580 mm mm

Utförande: Farmer 102 S Turbomatic, OECD 518

Mätning: to top of steering wheel

Höjd2 320 mm

Utförande Farmer 102 S Turbomatic, OECD 518 · to top of protection frame

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 2320 mm mm

Utförande: Farmer 102 S Turbomatic, OECD 518

Mätning: to top of protection frame

Däck

Fendt Farmer 102 S · Däck
UppgiftVärde och utförandeKälla
Framdäck7.50-16

Utförande Farmer 102 S Turbomatic, OECD 518 · tested front tyre, AS 6 ply

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 7,50-16 AS size

Utförande: Farmer 102 S Turbomatic, OECD 518

Villkor: tested front tyre, AS 6 ply

Bakdäck14.9-30

Utförande Farmer 102 S Turbomatic, OECD 518 · tested rear tyre, AS 6 ply

Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

Källans värde: 14,9-30 AS size

Utförande: Farmer 102 S Turbomatic, OECD 518

Villkor: tested rear tyre, AS 6 ply

Oljemängder och oljetyp

Oljevolymer, oljespecifikationer och serviceintervall.

Angivna fyllnadsmängder och serviceuppgifter enligt respektive källa
UppgiftVärde och utförandeKälla
Motorolja7,75 l Farmer 102 S Turbomatic, OECD 518 · engine lubrication
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 5. Oil capacity 7,75 l. Oljebyte 100 timmar. Patronen är utbytbar men inget timintervall för oljefiltret är tryckt. Vid provet användes HD SAE 20W/20 MIL-L-2104 B.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: engine lubrication

Transmissionsolja25,75 l Farmer 102 S Turbomatic, OECD 518 · speed change gear, group gear and fine stepped transmission
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 7. Speed change gear, group gear and fine stepped transmission 25,75 l. Kuggreduktionen 5,7 l, vätskekopplingen 4,1 l och slutväxlarna each 2,9 l ingår inte.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: speed change gear, group gear and fine stepped transmission

Transmissionsolja5,7 l Farmer 102 S Turbomatic, OECD 518 · spur gear reduction gear
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 7. Spur gear reduction gear 5,7 l, egen volym. Ingår inte i 25,75 l.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: spur gear reduction gear

Hydraulik15,5 l Farmer 102 S Turbomatic, OECD 518 · hydraulic tank
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 10. Hydraulic oil tank with 15,5 l capacity. Egen behållare. Oljebyte 1000 timmar. Vid provet användes HLP 25.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: hydraulic tank

Oljespecifikation · engineMIL-L-2104 C eller MIL-L-46152 Farmer 102 S Turbomatic, OECD 518 · engine
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 5. Recommended oil quality MIL-L-2104 C or MIL-L-46152. Viskositet vinter HD SAE 10W, sommar HD SAE 20W/20, tropik HD SAE 30. Provfyllningen var MIL-L-2104 B.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: engine

Oljespecifikation · gearboxSAE 80 MIL-L-2105 A Farmer 102 S Turbomatic, OECD 518 · gearbox
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 7. Other gears: transmission oil SAE 80 MIL-L-2105 A.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: gearbox

Oljespecifikation · final drivesSAE 90 MIL-L-2105 B Farmer 102 S Turbomatic, OECD 518 · final drives
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 7. Final drives: hypoid oil SAE 90 MIL-L-2105 B. Bak each 2,9 l.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: final drives

Oljespecifikation · fluid couplingHD SAE 10W Farmer 102 S Turbomatic, OECD 518 · fluid coupling
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 7. Fluid clutch: engine oil HD SAE 10W. Volym 4,1 l, byte 5000 timmar. Ingår inte i växellådans 25,75 l.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: fluid coupling

Oljespecifikation · hydraulic tankSAE 20W/20 MIL-L-2104 C eller MIL-L-46152 Farmer 102 S Turbomatic, OECD 518 · hydraulic tank
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 10. Engine oil (HD) SAE 20W/20 MIL-L-2104 C or MIL-L-46152. Vid provet användes HLP 25.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: hydraulic tank

Serviceintervallmotorolja 100 h; transmissionsolja 1 000 h; hydraulolja 1 000 h Farmer 102 S Turbomatic, OECD 518 · engine oil, gears and hydraulic tank
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 5: motorolja 100 timmar. Oljefilterpatronen är utbytbar men timintervallet är inte tryckt, så engine_filter utelämnas och intervallet är ofullständigt. Sida 7: gears 1000 hours. Vätskekopplingens 5000 timmar ingår inte. Sida 10: hydraulolja 1000 timmar. Inget hydraulfilterintervall är tryckt.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: engine oil, gears and hydraulic tank

Bränsle och kylvätska

Angivna volymer enligt respektive källa
UppgiftVärde och utförandeKälla
Kylvätska10 l Farmer 102 S Turbomatic, OECD 518 · cooling
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 5. Water capacity 10 l.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: cooling

Bränsletank73 l Farmer 102 S Turbomatic, OECD 518 · fuel tank
Källa

OECD Report No. 518, DLG Test No. 75-54 — Fendt Farmer 102 S Turbomatic

Utgivare: Deutsche Landwirtschafts-Gesellschaft e. V.

OECD 518, DLG Test No. 75-54, Fendt Farmer 102 S Turbomatic. Sida 4. Capacity of fuel tank 73 l.

Utförande: Farmer 102 S Turbomatic, OECD 518

System: fuel tank

Jämför modelluppgifter

Jämför publicerade faktarader och deras källvillkor mellan modellprofiler.

Välj en modell för att se de faktarader som har källgranskats.

Källor

Öppna källposten för publikation, variant, period och metod.

Om underlaget
Modellkod
Farmer 102 S
Serie
Farmer
Generation
No generation designation stated. DLG names the historical Farmer 102 S Turbomatik; keep it distinct from later Vario models.
Marknad
German DLG/OECD test context only; report location and testing do not establish a sales market or Swedish availability.
Källperiod
Report No. 518 was printed June 1976; tests ran September–October 1975. No model year, production interval or PIN boundary is stated.

Avgränsat källunderlag · status gap · omfattning comparisonFacts.

En fullständig granskning av hela modellguiden är inte dokumenterad.

Tidigare redaktionella källnoteringar
Öppna kontrollfrågor (5)
  • The source names a 1975 test and 1976 report only; model year, production interval, generation and PIN range are not stated.
  • The German DLG/OECD testing context does not establish a sales market or Swedish availability.
  • The individual serial and test-only weight/tyre/ballast configuration do not define every production tractor.
  • The report contains optional/non-fitted equipment and an erratum; full market options and owner/service information are outside this source.
  • No full-guide assessment is proposed from this single test report.
